Progressive Hardware Co., Inc

Edge Protection for In-Swinging Doors

Edge Protection for Out Swinging Doors
#1033 Latch Guard  3" x 11"  massive wrought steel, fits key-in-knob or mortise locks.  Complete with carriage bolts, acorn nuts and washers. Individually poly bagged. Packed 12 per box.
#1033SL - Silver Bake Kote
#1033DU - Duro Bake Kote

#1077 Latch Guard, 2-5/8" x 12"  wrought steel, 1/4" offset, 1-1/8" backset, 1-7/16" cylinder hole. Protects both latch and bolt. Reversible. Supplied with carriage bolts, acorn nuts and washers. Poly bagged. 12 per box.
#1077SL - Silver Bake Kote      #1077DU - Duro Bake Kote

#1077WO Latch guard, 2-5/8" x 12" wrought steel. Same as above #1077 but without cylinder hole. Packed 12 per box.
#1077WO/SL - Silver Kote          #1077WO/DU - Duro Kote
#1088 Latch Guard, 2-5/8" x 7", heavy guage steel, 1/4" offset, 1=1/8" backset, 1-7/16" cylinder hole. Protects latch or bolt. Reversible. Supplied with carriage bolts, acorn nuts and washers. Packed 12 per box.
#1088SL - Silver Kote                       #1088DU - Duro Kote

#1088WO Latch Guard, 2-5/8" x 7". Same as above #1088 but without cylinder hole. Packed 12 per box
#1088WO/SL - Silver Kote                #1088WO/DU - Duro Kote

#1099 Offset Latch Guard, 2-5/8" x 7". heavy gauge steel with cutout for up to 3-1/2" rose. 1/4" offset. For deadbolt or key-in-knob latchsets. Packed 12 per box
#1099SL - Silver Kote                        #1099DU - Duro Kote

Mortise Cylinder Protection

#1045 - Mortise cylinder guard plate. 10" x 4", can either replace existing trim or go over existing trim, up to 8". 1/2" high cylinder bubble.
Supplied with 4 each: carriage bolts, cap nuts and washers. Extra heavy steel. Available in Brass Plated or Chrome Plated. DIMENSIONS
#1045BP - Brass Plated    #1045CP - Chrome Plated

#1044 - Same as above but with 1/4" high bubble.
#1044BP - Brass Plated     # 1044CP - Chrome Plated

#1204 - 12" x 4" Mortise Cylinder Guard Plate, can cover up to a 10" escutcheon. Supplied with 4 each: carriage bolts, cap nuts and washers. Extra heavy steel. Available in Brass Plated or Chrome Plated.  DIMENSIONS
#1204BP - Brass Plated      #1204CP - Chrome Plated

#1204NYC - Same as #1204 but supplied with carriage bolts and sex nuts for use with certain NYCHA projects.
#1204BP-NYC - Brass Plated     #1204CP-NYC - Chrome Plated

#1066 Adjustable Mortise Cylinder Guard, 3" x 11". Replaces existing trim. Adjustable rose allows this plate to fit virtually any mortise lock. Raised bubble covers mortise cylinder and prevents wrenching of cylinder. SUpplied with four carriage bolts and sex bolts. Extra heavy steel. Available finishes are Gold Bake Kote and Silver Bake Kote.   DIMENSIONS
#1066GP - Gold Kote               #1066SL - Silver Kote

#103 Rim Lock Cylinder Guard - 5-7/8" x 3" x .090 wrought steel. 3/16" center raise for cylinder. Includes carriage bolts, nuts and washers.  DIMENSIONS
#103BP - Brass Plated           #103CP - Satin Chrome Plated
Document
1204 DIMENSIONS
Document
1044/1045 DIMENSIONS
Document
1066 DIMENSIONS
Document
103 DIMENSIONS
63 Brightside Ave. East Northport, NY 11731  631-757-8866
